With Clutch Compressor

Technical Specifications

Brand ZEPLIN Original

Cooling Water

Crankshaft Thread M12x1.5 RH

Cylinder Diameter Ø92 mm

Direct Action No

ESS Feature Yes

Maximum Working Pressure 12.5 bar

Number of Cylinders 2

Piston Stroke 57 mm

Port 0 M26x1.5

Port 2 Ø16 mm

Port 4 M16x1.5

Port 8.1 Ø4.5 mm

Port 9.1 M16x1.5

Port 9.2 M16x1.5

Volume 760 cm³

Water Cooled Valve Plate Yes

Weight 29.5 kg

Cylinder Head Repair Kit

ZEP0024171

Show More

Used In Vehicles

BrandModelEngine

Volvo FH Euro 6

Volvo FM Euro 6

Volvo FMX Euro 6

Documents

ZEP0024109 request documents for Request

Keywords

ZEP0024109 With Clutch Compressor 01.04.266 Knorr-Bremse LS8902 K100417N06 K100417N07 K044773N06 K044773N07 K093380N06 K093380N07 K093380N56 K093380N57 K100417C06 K100417C56 K100417C57 K100417N00 K100417N56 K100417N57 K100417X00 K162777C56 K162777N56 K162777X00 K168639N06 K168652C56 K168652N00 K168652N06 K168652N56 K168652X00 K047190N06 K047190N07 K093387N06 K093387N56 K100419C56 K100419C57 K100419N56 K100419X00 K162834C56 K162834C57 K162834N00 K162834N06 K162834N07 K162834N56 K162834N57 K162834S01 K162834X00 K168064N00 K168064N06 K168655C56 K168655C57 K168655N00 K168655N06 K168655N06 K168655N07 K168655N56 K168655N57 Volvo 23366838 23670686 22147345 21702091 21702092 22083150 22083158 22147324 23432714 21702069 22083142 23432716
