    Single Cylinder Compressor

    ZEPLIN® No: ZEP0016111

    Compare

    GTIN
    8680437137252

    OEM Numbers

    Wabco
    Mercedes-Benz

    Brand and Model

    Mercedes-Benz

    Axor,

    Atego,

    Atron

    Technical Specifications

    Brand ZEPLIN Original

    Cylinder Diameter Ø100,00

    Volume 393 cm³

    Piston Operating Distance 50 mm

    Port 0 Ø30 mm

    Port 2 M26x1.5

    Port 8.1 Ø 6 mm

    Crankshaft Thread M20x1.5 LH

    Port 9.1 M14x1.5

    Port 9.2 M14x1.5

    Number of Cylinders 1

    Cooling Water

    Water Cooled Valve Plate Yes

    Direct Working Yes

    Maximum Operating Pressure 12.5 bar

    Weight 15 kg
