Single Cylinder Compressor

Technical Specifications

Brand ZEPLIN Original

Cooling Water

Crankshaft Thread M18x1.5 RH

Cylinder Diameter Ø100 mm

Maximum Working Pressure 12.5 bar

Number of Cylinders 1

Piston Stroke 46 mm

Port 0 M26x1.5

Port 2 M26x1.5

Port 9.1 M22x1.5

Port 9.2 M22x1.5

Volume 360 cm³

Water Cooled Valve Plate Yes

Weight 17.7 kg

Complete Cylinder Head

ZEP0002171

Repair Kit

ZEP0002172

Repair Kit

ZEP0002174

Repair Kit

ZEP0002176

Repair Kit

ZEP0003542

Repair Kit

ZEP0002190

Cylinder Liner Set

ZEP0002179

Piston & Ring

ZEP0001769

Piston & Ring

ZEP0003366

Piston & Ring

ZEP0003367

Piston & Ring

ZEP0003368

Piston & Ring

ZEP0003369

Show More

Used In Vehicles

BrandModelEngine

Man FE26T 6x4 D2876

Documents

ZEP0000487 request documents for Request

Keywords

ZEP0000487 Single Cylinder Compressor 01.01.003 Man 51.54100-6015 51.54100-6013 51.54100-6011 51.54100-9015 51.54100-7025 51.54100-7177 51.54100-7179
