Single Cylinder Compressor

Technical Specifications

Brand ZEPLIN Original

Cooling Water

Crankshaft Thread M20 x 1.5 RH

Cylinder Diameter Ø75 mm

Direct Action Yes

ESS Feature Yes

Maximum Working Pressure 10 bar

Number of Cylinders 1

Piston Stroke 56 mm

Port 0 1-1/16"-12 UN-2B

Port 2 1-1/16"-12 UN-2B

Port 4 1/8" -27 NPTF

Port 8.1 7/16" -20 UNF-2B

Port 9.1 3/4" -16 UNF-2B

Port 9.2 3/4" -16 UNF-2B

Volume 247 cm³

Water Cooled Valve Plate Yes

Weight 15 kg

Complete Cylinder Head

ZEP0023054

Piston & Ring

ZEP0002678

Piston & Ring

ZEP0003350

Piston & Ring

ZEP0003352

Piston & Ring

ZEP0003353

Used In Vehicles

BrandModelEngine

Freightliner

Documents

ZEP0024259 request documents for Request

Keywords

ZEP0024259 Single Cylinder Compressor 01.05.179.10 Freightliner TDAS9111545180 Wabco 911 154 518 0 911 154 518 9 911 154 512 0
